Shelly PRO DIMMER 2PM

Product Introduction

The Shelly Pro Dimmer 2PM is a professional-grade dual-channel smart dimmer designed for installation inside electrical distribution boards using a DIN-rail mounting system. It allows users to control and dim two lighting circuits independently while monitoring their energy consumption in real time.

Designed for both residential and commercial automation systems, the device supports dimmable LED lighting, halogen lamps, and compatible transformers operating on 110–240 V AC. The integrated power monitoring function measures voltage, current, and energy consumption for each channel, helping users optimise electricity usage.

With built-in Wi-Fi, LAN, and Bluetooth connectivity, the Shelly Pro Dimmer 2PM offers reliable network communication and flexible integration with modern smart home platforms. Its advanced automation capabilities make it ideal for intelligent lighting control in homes, offices, and commercial installations.

Key Features

Dual-Channel Smart Dimming Control
Controls and dims two independent lighting circuits from a single DIN-rail device.

Integrated Power Monitoring
Measures voltage, current, and energy consumption for each channel to track power usage.

Professional DIN-Rail Installation
Designed for mounting in electrical distribution boards for professional smart building installations.

LAN, Wi-Fi, and Bluetooth Connectivity
Supports Ethernet LAN, Wi-Fi, and Bluetooth for flexible connectivity and reliable communication.

Automatic Dimming Calibration
Automatically detects and calibrates compatible lighting loads for smooth brightness control.

Advanced Automation and Scripting
Supports schedules, automation rules, scripting, MQTT, webhooks, and integration with automation platforms.

Smart Home Integration

The Shelly Pro Dimmer 2PM integrates with multiple smart home ecosystems and automation platforms.

Supported integrations include:

• Shelly Smart Control App
• Amazon Alexa
• Google Home
• Home Assistant
• MQTT and REST API automation systems

Once connected, the device can participate in automation scenarios such as:

• Automatically adjusting lighting brightness throughout the day
• Creating custom lighting scenes for rooms or buildings
• Monitoring energy consumption of lighting circuits
• Scheduling lights to dim or switch off at night

Technical Specifications

Product Type: Professional Smart Dimmer with Power Monitoring
Model: Shelly Pro Dimmer 2PM
Channels: 2 independent dimming outputs
Dimming Type: Trailing edge dimming
Power Supply: 110–240 V AC, 50/60 Hz
Maximum Output Power: Up to 200 W per channel
Connectivity: Wi-Fi 2.4 GHz, Ethernet (LAN), Bluetooth
Power Monitoring: Voltage, current, and energy measurement
Mounting: DIN-rail installation
Operating Temperature: −20 °C to 40 °C
Material: Plastic enclosure

What’s in the Box

Shelly Pro Dimmer 2PM smart dimmer
Quick start guide
